Linear Vibrating Screen

ZKB series linear vibrating screen is double motors drove. It can be used in screening and classifying for powder, widely used in plastics, abrasives, chemicals, pharmaceuticals, building materials, food, carbon, fertilizer and other industries. Applies to screening for the particle size 0.074-5mm, the water content less than 70%, non-sticky dry powder. The maximum feeding size could not bigger than 100mm.


DescriptionParameter

Description
ZKB series linear vibrating screen is double motors drove. It can be used in screening and classifying for powder, widely used in plastics, abrasives, chemicals, pharmaceuticals, building materials, food, carbon, fertilizer and other industries. Applies to screening for the particle size 0.074-5mm, the water content less than 70%, non-sticky dry powder. The maximum feeding size could not bigger than 100mm.

Advantages and Characteristics
1 Adopting eccentric block as strong exciting force;
2 Less energy consumption, lower noise and longer sieve service life;
3 The beam and screen box are joined by high strength helix and without welding;
4 Adopt tire coupling, soft connection makes operation smooth;
5 High accuracy screening ratio, adjustable particle size, large capacity, high screening efficiency and long life;
6 Fully sealed structure, automatic layout, more suitable for assembly line work;
7 Simple and stable structure, convenient maintenance.

Main Technical Parameters

Model

Layer

Mesh size

(mm)

Feeding size
(mm)

Capacity

(t/h)

Double-amplitude
(mm)

Vibration angle

( °)

Power

(Kw)

ZKB0936

1

5~25

<100

40

6~8

45

3*2

2ZKB1020

2

8~25

<100

60

6~8

45

3*2

ZKB1025

1

8~25

<100

60

6~8

45

3*2

ZKB1225

1

8~25

<100

80

6~8

45

3*2

ZKB1236

1

10~25

<100

100

6~8

45

5.5*2

2ZKB1236

2

25~50

<100

150

6~8

45

5.5*2

2ZKB1437

2

25~50

<100

200

6~8

45

5.5*2

ZKB1542

1

25~50

<100

200

6~8

45

5.5*2

ZKB1756

1

25~50

<300

300

6~8

45

11*2

2ZKB1756

2

25~50

<300

400

6~8

45

11*2

ZKB1836

1

25~50

<300

400

6~8

45

11*2

2ZKB1848

2

25~80

<300

600

6~8

45

11*2

ZKB1856

1

25~80

<300

500

6~8

45

11*2

2ZKB1856

2

25~80

<300

600

6~8

45

15*2

ZKB1863

1

25~80

<300

500

6~8

45

15*2

2ZKB2065

2

25~80

<300

1000

6~8

45

15*2

ZKB2452

1

25~80

<300

800

6~8

45

15*2

ZKB2460

1

25~80

<300

800

6~8

45

15*2

2ZKB3060

2

25~80

<300

1000

6~8

45

22*2

ZKB3675

1

25~80

<300

1500

6~8

45

22*2
